Tubes:
Titanium grade 9 (3Al / 2,5V) with different thicknesses, drawn and strengthened. Titanium grade 5 (6Al / 4V) for head tube, bottom bracket shell and dropouts, CNC works.
Front Triangle:
Round tubes, top tube Ø 31.8 mm, seat tube Ø 31.8 mm, downtube Ø 48mm bi-oval.
Rear Triangle:
Round seat stays taper Ø 16 mm. Oval chain stays taper 21 x 27 mm S-shaped.
Bottom Bracket Shell:
Titanium grade 5, CNC machined, Passoni engraved logo and frame code, T47 system.
Headtube:
Integrated conical Ø 56mm, CNC machined, bearings Ø 1”1/8 upper 1”1/2 lower.
Dropouts:
Titanium grade 5 CNC machined, Ergal insert for disc brake thru-axle support.
Seatpost:
Traditional seat post.
Fork:
Deda Edg Ø 56 mm, thru-axle 100 x 12 customised Passoni.
options:
The frame is available for mechanical groupset, Di2/EPS groupset or wireless groupset. The bike is also available with rim brakes.
